Wholesale VOE14346715 Rockmaster/4SP for Volvo Excavator

Wholesale VOE14346715 Rockmaster/4SP for Volvo Excavator

Volvo EW160(SER NO 1001-1912) excavator spare part VOE14346715 Rockmaster/4SP

Part Name: VOE14346715 Hydraulic hose

KDSORT: 270

UE: U

NS_SS: OP

ANT1: 1

Hose Recipe Asmoverall Length MM: 250

Hose Recipe Asmoverall Length Inch: 9.84

Hose Recipe Asmoverall Length ToL MM: +/- 3mm

Hose Recipe Asmoverall Length ToL inch: +/- 0.118"

Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 3 degrees

Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)

Hose Recipe Safety Standard: EN 982-1996

Hose Recipe Assembly Instruction Reference: 1076838

Hose Recipe Version: 2

Hose Recipe Status: A

Hose Recipe Vendor: MANULI

Hose Recipe Grade: 1

Hose Part Hose Description: Rockmaster/4SP

Hose Part Hose Size DN: 10

Hose Part Hose Size Inch: 3/8"

Hose Part Hose Dash: -06

Hose Part Hose Pressure Class MPA: 45.0

Hose Part Hose Pressure Class PSI: 6525

Hose Part Hose Pressure Class BAR: 450

Hose Part Hose Standard ISO: ISO 3862 4SP

Hose Part Hose Standard SAE: Volvo 102

Hose Part Hose Standard EN: EN 856 4SP

Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1

Hose Part Hose Structure: Wire spiralled four layer

Hose Part Hose Remark: Abrasion, weather and heat resistance

Hose Part Hose Outer Diameter MM: 21

Hose Part Hose Outer Diameter INCH: 0.83

Hose Part Cancelled: N

Hose Part Vendor: MANULI

Hose Part Grade: 1

Hose Part In Program: Y

Catalog: 99536/911/2700, 99530/911/2700, 99531/911/2700

Looking for Part NO.VOE14346715?
We supply SAMSUNG / ISUZU / SUMITOMO / CUMMINS / Doosan / KATO spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
VOE14346715 for Volvo Hydraulic system, X3(LE265A assembly)

Volvo VOE14346715 Hydraulic hose suitable for LE265A Hydraulic system, X3 assembly.

Volvo VOE14346715(c.LE265A) Hydraulic hose

Ref: LE265A / 18 / 1

VOE14303049(VOE11707926) / U / X3 Hydraulic funcion

99531/911/2700

VOE14346715 for Volvo Hydraulic system, X3(LD302A assembly)

Volvo VOE14346715 Hydraulic hose suitable for LD302A Hydraulic system, X3 assembly.

Volvo VOE14346715(c.LD302A) Rockmaster/4SP

Ref: LD302A / 18 / 1

VOE14303049(VOE11707926) / U / X3 Hydraulic funcion

99530/911/2700

VOE14346715 for Volvo Hydraulic system, X3(LK276A assembly)

Volvo VOE14346715 Rockmaster/4SP suitable for LK276A Hydraulic system, X3 assembly.

Volvo VOE14346715(c.LK276A) Hydraulic hose

Ref: LK276A / 18 / 1

VOE14303049(VOE11707926) / U / X3 Hydraulic funcion

99536/911/2700

china excavator parts supplier offer Doosan / Hitachi / HYUNDAI / Kubota / KATO / CASE spare parts. MOQ 1 pcs is available! VOLVO Part NO.VOE14346715 is on sale now!
Part NO. VOE14346715 for Volvo EC160(SER NO 1001-)

EXCAVATOR VOLVO EC160

BASIC MACHINE

PROD NO 14301063 EC160 CHN, SER NO 1001 - 1059

PROD NO 14301064 EC160 CHW, SER NO 1001 - 1113

CAB

PROD NO 14371423

ENGINE

Part No. 14371017 Type TD 40 GHE, 14301063 = SER NO - 1021

Part No. 14371017 Type TD 40 GHE, 14301064 = SER NO - 1047

Part No. 14370943 Type TD 40 KGE, 14301063 = SER NO 1022 - 1049

Part No. 14370943 Type TD 40 KGE, 14301064 = SER NO 1048 - 1095

Part No. 14373449 Type TD 40 KGE, 14301063 = SER NO 1050 -

Part No. 14373449 Type TD 40 KGE, 14301064 = SER NO 1096 -

Part NO. VOE14346715 for Volvo EW140(SER NO 1001-1487)

EXCAVATOR VOLVO EW140

BASIC MACHINE

PROD NO 14301062 EW140, SER NO 1001 - 1487

CAB

PROD NO 14371423

ENGINE

Part No. 14371017 Type TD 40 GHE. SER NO - 1362

Part No. 14373450 Type TD 40 GHE. SER NO 1363 -

Part NO. VOE14346715 for Volvo EW160(SER NO 1001-1912)

EXCAVATOR VOLVO EW160

BASIC MACHINE

PROD NO 14301065 EW160, SER NO 1001 - 1912

CAB

PROD NO 14371423

ENGINE

Part No. 14370943 Type TD 40 KGE. SER NO - 1742

Part No. 14373449 Type TD 40 KGE. SER NO 1743 -
